4. Installing the Equipment: Base Stand (Optional)
4.7
Leveling the Equipment
Required Tool
1.
Prepare a Spirit Level.
2.
Turn the Rotating Unit clockwise so that the X-ray tube head faces the front.
3.
Turn all nine screws in marked locations clockwise.
64
T-shaped Hex
Wench
Spirit Level
Ensure to place the Spirit Level on the indicated
locations in this manual for an accurate reading.
vatech A9 (Model:PHT-30CSS)
8 mm / 0.3"
N/A
Installation Manual
