4.2
Installing the CEPH Unit (Optional)
1.
Open the CEPH box and take out the components.
2.
Remove the plastic wrap covering the Column Unit and the CEPH cable.
3.
Push the CEPH arm in the direction indicated below. Ensure that all four studs
come through holes.
vatech A9 (Model: PHT-30CSS)
4. Installing the Equipment: Base Stand (Optional)
DO NOT hold the areas of the collimator, sensor, and tube
head.
Installation Manual
47
