4. Installing the Equipment: Base Stand (Optional)

4. Installing the Equipment: Base Stand
(Optional)
4.1

Assembling the Base and Main Units

1. Remove bolts on the lower carrying handle using an Allen Wrench.
Required Tool
42
If you are installing the equipment on a concrete floor, go to t
4.4 Fixing the base (Optional) and complete step 1 first.
Then return to the 4.1 Assembling the Base and Main Unit.
Allen Wrench 6 mm / 0.24"
vatech A9 (Model:PHT-30CSS)
Installation Manual
