4. Installing the Equipment: Base Stand (Optional)
4.5
Connecting the Cables to the Equipment.
1.
Connect the Ethernet and other cables in the back of the Column Unit as shown
in the figure.
Parts and
Accessory
Exposure
Switch
Indicator
(Optional)
60
Ethernet Cable
Cable Tie
Exposure Switch
Ethernet Cable
vatech A9 (Model:PHT-30CSS)
(Part No. 21)
(Part No. 20)
(Part No. 2)
Installation Manual
