2.
Put two wrench bolts into the holes (see below) and loosely tighten them with
an Allen Wrench to connect the Base Unit to the Column Unit.
Required Tool
Parts and
Accessory
vatech A9 (Model: PHT-30CSS)
4. Installing the Equipment: Base Stand (Optional)
Allen Wrench
6 mm / 0.24"
M8 x 20 - 2 pcs
Wrench Bolt
(Part No. 24)
Put the bolts into the holes until about 15 mm are left
outside.
Installation Manual
43
