User Manual NV200 Spectral Range
<< Back to Contents
TECHNICAL DATA
3.1 Dimensions
The dimensions below are for the NV200 Spectral with 500 note cashbox. Other
cashbox / module options will change the dimensions. For dimensional drawings of
other configurations contact
3.2 Weight
The tables below show the weights for the individual components of the product.
For example, and NV200 Spectral with Standard Bezel and 500 Note Cashbox with
Chassis would weigh 3.21Kg (1.20 Kg + 2.01 Kg).
3.2.1 Standard Unit – No Cashbox
Unit
NV200 Spectral – Standard Bezel
3.2.2 Cashbox Options
Unit
500 Note Cashbox with Chassis
1000 Note Cashbox with Chassis
2200 Note Cashbox with Chassis
TEBS Cashbox (Tamper Evident Bag System
Copyright © Innovative Technology Ltd 2019
support@innovative-technology.co.uk
Weight Empty
1.20 Kg
Weight Empty
2.01 Kg
2.19 Kg
3.15 Kg
6.95 Kg
Weight Full
N/A
Weight Full
2.46 Kg
3.09 Kg
4.99 Kg
7.75 Kg
Doc: GA02119 User Manual NV200 Spectral Range
Version: 2.2
Page 12 of 113
