User Manual NV200 Spectral Range
<< Back to Contents

5.4.2.3 Re-programming via SD Card

Follow the steps below to set up the SD card and perform the update:
1) Connect the SD card to your PC using an SD card reader.
2) Ensure that the card is FAT-32 formatted and is blank.
3) Create a folder on the SD card called nv200hs. This must be lowercase
4) Inside the folder, place the dataset file that you want to load on to the validator.
Datasets can be downloaded from the
requested from our support team:
5) Ensure the NV200 Spectral is powered on and has booted up
6) Insert the SD card into the slot on the front. The bezel will now start flashing.
Do not unplug the validator during the update process.
7) Wait until the bezel lights solid green. When it does, the SD card can be
removed.
8) After the SD card has been removed, the unit will reboot. This takes around 10
seconds. Once it has rebooted the NV200 Spectral will have the new dataset on
it and is ready to be used. If there are modules attached
(Payout/Ticket/TEBS) these will then be updated by the NV200
Spectral, do not unplug the unit during these updates.

5.4.3 Remote Updates

5.4.3.1 General Description

The unit can be updated through an SSP command which sets the validator into an
update mode before downloading the firmware file. Details of how this process is
implemented can be found in ITL's eSSP Implementation Manual (GA973) and is
available on request.
Copyright © Innovative Technology Ltd 2019
Innovative Technology website
support@innovative-technology.co.uk
Caution!
This is a complex operation and
failure to implement correctly
may damage units.
Doc: GA02119 User Manual NV200 Spectral Range
or
Version: 2.2
Page 49 of 113
