Summary of Contents for Innovative Technology BV100

  • Page 1 BV100 OPERATIONS MANUAL Innovative Technology assume no responsibility for errors, omissions, or damages resulting from the use of information contained within this manual.

  • Page 2: Table Of Contents

    7 DIAGNOSTICS..............................21 8 SUPPORT ................................22 9 APPENDIX ................................. 23 9.1 APPENDIX A – HOW TO ORDER A BV100 VALIDATOR ................23 9.2 APPENDIX B – BV100 MECHANICAL INSTALLATION ................24 9.3 APPENDIX C – BV100 CASH BOXES ......................25 9.4 APPENDIX D –...

  • Page 3: Introduction

    CAUTIONS • This product must be fitted with a 3 A (ampere) fuse before use. • The BV100 validator is pin for pin compatible with NV7/8/9/10, but not pin for pin compatible with the NV2/3/4/4x or 5 series products. • Due to different note cycle times there may be timing differences from the NV products.
  • Page 4 Tel: +44 161 626 9999 Fax: +44 161 620 2090 E-mail: support@innovative-technology.co.uk Web site: www.innovative-technology.co.uk AUSTRALIA support@innovative-technology.com.au BRAZIL suporte@bellis-technology.com.br CHINA support@innovative-technology.co.uk GERMANY supportDE@innovative-technology.eu ITALY supportIT@innovative-technology.eu SPAIN supportES@innovative-technology.eu UNITED KINGDOM support@innovative-technology.co.uk REST OF THE WORLD support@innovative-technology.co.uk Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 5: Environment And Power Requirements

    Table 3 – Interface Logic Levels CAUTION · If the input voltage falls below 11.5 V the BV100 may not operate correctly (will reject notes). The front bezel lights will flash to indicate incorrect conditions. · It is recommended that the power supply used can supply at least 2.5 amperes.

  • Page 6: General Description

    Secure lock for the cash box A lock can be fitted to the BV100 to secure the cash box in place (lock part number PA650) Note: A locking cam (MC229) must also be fitted.
  • Page 7 110 V AC supply. · Low power option The BV100 has a low power option to reduce the power consumption when idle. To learn more about the low power option, please refer to the Chapter 5.

  • Page 8: Machine Interfaces

    An example mating connector is Molex type Part No: 39-51-2160. It is possible to use the special hardware versions of BV100 in machines operating at 110 volts or in machines operating at MDB. The BV100 also has a Configuration Button located above the USB Connector (See Figure 2).

  • Page 9: Interface Connector Pin Details

    Inhibit 4 Inhibit channel 4 by holding this pin HIGH Busy BV100 is validating and stacking output. Active low while the BV100 is reading, transporting or stacking a note Escrow Operate Escrow function by holding LOW (see Appendix B –...

  • Page 10: Configuration Button Functions

    LED will flash rapidly to indicate that SSP is being loaded. Once this process has finished the BV100 will reset. The BV100 will now be in Programming Mode (SSP) and allow connection to a PC via a DA1 or DA2 adapter or connection to a DA3.

  • Page 11: Protocols

    (GA138), this is available from the ITL website www.innovative-technology.co.uk. To help in the software implementation of the SSP, ITL can provide DLL controls and Visual Basic applications on request. Please contact support@innovative-technology.co.uk for more information. Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 12: Cctalk ® Protocol - Cct

    4.3.3 MULTI-DROP BUS/INTERNAL COMMUNICATIONS PROTOCOL (MDB/ ICP) To use the MDB mode an MDB BV100 or an IF5 interface box can be used. The MDB interface must be programmed into the validator via the Configuration Cards (See Appendix D - Configuration Cards) or via the ITL BNV Currency Manager program.

  • Page 13: Serial Input/ Output - Sio

    SSP interface is recommended. CAUTION • The BV100 does not support the simple serial data out only mode as available on NV4 and earlier models NV2 and NV3. It only supports the serial data input/output mode. • The host machine does not echo messages back to the validator.
  • Page 14 BV100 Operations Manual The BV100 will receive and transmit the following event codes: Recognised Receive Codes to Transmitted codes from BV100 BV100 MESSAGE DECIMAL MESSAGE DECIMAL VALUE VALUE Inhibit C1 Note Accept on C1 Inhibit C2 Note Accept on C2...

  • Page 15: Table 9 Example Protocols

    Note accept in Escrow Mode Note entered into validator Validator Busy 120 Note Accepted Channel 2 Validator Ready 121 Accept on Channel 2 2 172 Accept Note in Escrow Accept Escrow 172 Accept on Channel 2 2 Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 16: Parallel Input And Output

    Busy Output: (Pin 9). This is a general-purpose busy signal. It is active low while the BV100 is in operation. Escrow Control: (Pin 10) Hold this pin Low to enable the single note escrow function. (See Appendix E –...

  • Page 17: Binary Output - Bin

    BV100 can be set to give a binary pattern output on the four parallel output pins. If the BV100 is set to binary mode it will issue the vend signals as a binary pattern on the parallel outputs for 100 ±...

  • Page 18: Other Interfaces Available Upon Request By Itl

    Programming the BV100 with the configuration cards is enabled via the ‘Configuration Button’ on the right hand side of the BV100 (see Chapter 4.2.3). (For details on how to complete the configuration cards please see Appendix D – Configuration Cards).

  • Page 19: Low Power Option

    BV100 when idle. When the BV100 is in this state the current consumption is reduced. The BV100 goes into low power mode approximately 6 seconds after the validator is powered up and remains in this state until a note is entered (Time A, Figure 10).
  • Page 20 (Time A). When a note is inserted under the front sensor the BV100 wakes up and the busy line goes low to indicate that the validator is in use. The busy line remains low during the validating and stacking process and once the note has been successfully validated and stacked the vend line goes low to issue the credit.

  • Page 21: Re-Calibration

    The BV100 has an in-built self-calibration system that maintains the optical sensors at their best operating point. However if the BV100 is disassembled for any reason it will need to be re-calibrated. Re-calibration may only be performed under license from ITL, contact support@innovativetechnology.co.uk...

  • Page 22: Diagnostics

    Motor Foreign object or Ensure the note path is clear and reset the continues to note is stuck in validator. It may also be necessary to reset the host the note path machine. Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 23: Support

    (see the General Description chapter for operating system requirements). The BV100 can be connected directly via the USB port, or with either a DA1 kit fitted to the serial port or DA2 kit fitted to the USB port. (See Appendix F – Interface Tools DA1 – DA2)

  • Page 24: Appendix

    BV100 Operations Manual 9 APPENDIX 9.1 APPENDIX A – HOW TO ORDER A BV100 VALIDATOR To order a validator, please print and fill the order form, below, and send it to our nearest office. You may send it by fax or email. To find our contact information, please go to our website or refer to the introduction chapter in this document.

  • Page 25: Appendix B - Bv100 Mechanical Installation

    BV100 Operations Manual 9.2 APPENDIX B – BV100 MECHANICAL INSTALLATION In line with continued product development Innovative Technology Ltd reserves the right to change specification without prior notice. 1. 66 mm x 160 mm LONG 2. 72 mm x 160 mm LONG...

  • Page 26: Appendix C - Bv100 Cash Boxes

    BV100 Operations Manual 9.3 APPENDIX C – BV100 CASH BOXES Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 27: Appendix D - Configuration Cards

    7) If an error occurs has occurred the card will be rejected and the bezel LEDs will flash slowly a number of times to indicate the cause of the error. (see table below) 8) important check that the configuration requested has been set in the BV100 before use.
  • Page 28 A SSP interface will only ever flash once A ccTalk interface with 16 bit checksum, no encryption will flash 6,1 A ccTalk interface with 8 bit checksum, no encryption will flash 6,1,2 A Binary interface will flash 8,1 Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 29 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 30 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 31 BV100 Operations Manual Below are some typical examples of completed Configuration Cards. Note: These Configuration Cards are samples and should not be copied for programming use. Please see document GA713 for useable cards. Parallel Binary Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 32 Note: These Configuration Cards are samples and should not be copied for programming use. Please see document GA713 for useable cards. Unencrypted ccTalk with Pulse – Pulse width Encrypted ccTalk 50/100 mS 16-bit Checksum 4 Pulses per Dollar Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 33 BV100 Operations Manual Note: These Configuration Cards are samples and should not be copied for programming use. Please see document GA713 for useable cards. SIO 300-Baud SIO 9600-Baud Starts SIO 300-Baud SIO 9600-Baud Starts Disabled Disabled Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 34: Appendix E - Escrow Control

    30 second time-out. For channels above 4, setting all the inhibits high will cause a note reject. In the event of a note being forcibly removed from the mouth of the BV100 during the 30 second interval, the BV100 will go out of service for 45 seconds.

  • Page 35: Appendix F - Interface Tools Da1-Da2

    NOTE: The Validator must be in Programming mode when connected to a computer and then returned to the Original Settings when the download is complete. Figure 12 - Connecting DA1 to BV100 and PC for upgrading Validator programs Copyright Innovative Technology Ltd 2014...

  • Page 36: Figure 13 Connecting Da2 To A Bv100 And Pc For Upgrading Validator

    BV100 Operations Manual Connecting a DA2 to a validator and PC Figure 13 - Connecting DA2 to a BV100 and PC for upgrading Validator Programs Software Installation DA1 - To install the ITL BNV Download Manager Software insert the CDROM into the correct PC drive. The CD should automatically run and an installation menu will appear.

  • Page 37: Appendix G - Exploded Diagrams

    Crank arm - recess GA707 PM719 Belt drive wheel GA706 PM720 Belt drive wheel flange GA706 PM721 Flanged roller wheel GA706 PM722 Roller bush GA706 PM723 Roller wheel – clip in GA706 PM724 Pressure wheel GA708 Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 38: Table 12 Parts List

    CN279 Cable Assy GA708 MR108 Stacker motor only available as part of assembly MR111 Belt drive motor only available as part of assembly Table 12 – Parts list Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 39 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 40 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 41 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 42 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 43 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...
  • Page 44 BV100 Operations Manual Copyright Innovative Technology Ltd 2014 GA717-3...

  • Page 45: Index

    Figure 5 Pin detail Figure 6 ccTalk Connection pins on the BV100 Figure 7 MDB Opto Isolated Input / Output circuit BV100 MDB slave Figure 8 Typical Serial Output: Transmission of the value 20 (decimal), Note not recognized Figure 9...
  • Page 46 BV100 OPERATIONS MANUAL DRAWING NO AUTHOR DATE FORMAT GA717 10/10/07 MS Word 2000 ISSUE RELEASE DATE MODIFIED BY COMMENTS 10/10/07 First Draft 04/12/07 First Release 08/12/08 Updated IF30 information 06/01/09 General update 13/08/14 General Update Copyright Innovative Technology Ltd 2014 GA717-3...
