User Manual NV200 Spectral Range
<< Back to Contents
4.5 Docking Plate Mounting
When using the docking plate, you will need a different cable to connect the NV200
Spectral to the power supply as the connector is different.
1. Slide NV200
Spectral
Forward
Lift the latch on
the front of the
NV200 Spectral
head and slide it
forward on the
chassis
Copyright © Innovative Technology Ltd 2019
Doc: GA02119 User Manual NV200 Spectral Range
Version: 2.2
Page 31 of 113
