3. Remove red
insert
There are 2xT8
screws located on
the underside of
the NV200
Spectral, remove
those and lift away
the plastic insert.
4. Remove Locking
Cam
Press the plastic
clip together and
remove the locking
cam.
5. Remove Plastic
Insert
To remove the
plastic insert, from
the lock mount,
press the two clips
on the side
together and push
through. Insert the
cam lock in its
place.
