9.6 Clearing a Jam from the Ticket Module

If a Jam has occurred in the SMART Ticket Power must be Removed, once removed
disconnect the NV200 Spectral by lifting the red catch at the front of the NV200
Spectral and sliding it away from the cashbox, it is now possible to lift the Ticket
module away. With the NV200 Spectral removed the Ticket Path can be opened as
explained in Section 7.3.3.
Remove any visible blockage then remove the loaded tickets. Ensure there is no debris
built up in the SMART Ticket as explained in
Attach the NV200 Spectral and power. insert the paper once the unit has started up.

9.7 Clearing a Jam from the Safe Interface Module

Clearing a jam from the upper area of the Safe Interface Module is possible without
access to the safe. If a jam occurs between the Note Transport and the cashbox,
access to the safe will be required.
To clear the jam from the upper area:
1) Remove the NV200 Spectral Head
To remove the NV200 Spectral head from the Outer Docking Plate, lift the red
latch on the front of the unit and slide the NV200 Spectral Head forward
