Slide the cash bag back into the
TEBS and turn the lock – the lock
will go red. The stacker will
audibly cycle and the bezel flash
code will disable showing the
barcode has been read.

4.4 Lock Mounting

4.4.1 Lock Fitting

1. Lock Location
The Lock can be
fitted to the front
of the NV200
Spectral replacing
the red front insert
(shown to the
right) which ships
by default
2. Remove head
from chassis
Before the lock can
be installed,
remove the NV200
Spectral from the
cashbox chassis.
Lift the latch, slide
the head forward
and lift the head
away from the
chassis.
