To open the note path cover, pull the top cover release latch forward (towards the
bezel) and lift the cover as shown below (it is recommended to also remove the bezel
to allow correct cleaning of the note path guides):
Cover
release
latch
The note path is visible and can be cleaned. Carefully wipe the surfaces with a soft lint
free cloth that has been dampened (NOT wet) with a water and mild detergent solution
(e.g. household washing up liquid) - be very careful when cleaning around the sensor
lenses and make sure they are clean and dry before closing the cover and powering the
unit.
Caution!
Do not use any lubricants.
WARNING!
Do not try to disassemble
Copyright © Innovative Technology Ltd 2019
Do not lubricate any of the note transport
mechanism or any part of the note path, as this
can affect the operation of the validator.
Do not attempt to disassemble the validator
head – trying to do this could cause personal
injury and will damage the unit beyond
repair.
Doc: GA02119 User Manual NV200 Spectral Range
Note path guides
