MECHANICAL INSTALLATION

4.1 Compatibility

4.1.1 Hardware Compatibility

4.1.1.1 Machine Mounting

Assuming the suitable bezel (and cashbox) type has been ordered the NV200 Spectral
can be used as fitting replacement for the following ITL products only:
• NV200
Innovative Technology Ltd. has a policy of continuous product improvement. Due to
design changes older model or product bezels (and cashboxes) may not be compatible
with the NV200 Spectral. Specifically, the NV200 Spectral head is not backwards
compatible with the NV200 cashbox and chassis.
The 2200 note cashbox also has a larger chassis which means that it is not a suitable
replacement for current installations.
However, new product deliveries always include a bezel (and cashbox) that must be
used.

4.1.1.2 Machine Interfacing

By design the NV200 Spectral is pin to pin compatible with the suitable fitting
replacement products listed in
harnessing are required.

4.1.1.3 Power Supply

It is vital that the NV200 Spectral is connected to a power supply able to provide the
required power environment. A weak power supply causes malfunctioning of the NV200
Spectral such as note rejects or missing credits. If the NV200 Spectral is used as a
fitting replacement for an older model or product we recommend checking the power
supply specifications of the machine. The power supply of the machine might be
designed for the older model or product but not suitable for the NV200 Spectral. The
NV200 Spectral might have higher power consumption. Refer to
power requirement details of the NV200 Spectral.
Copyright © Innovative Technology Ltd 2019
Caution!
Only use bezels (and cashboxes)
shown in this manual
Section 4.1.1.1 No changes to existing machine
Caution!
A weak power supply may cause
malfunctioning!
Section 3.4
