PROTOCOLS AND INTERFACING

6.1 Introduction

The NV200 Spectral supports standard industry protocols. Interfaces that are not listed
may be available upon request. For any queries regarding interfaces that are not listed
contact support@innovative-technology.co.uk

6.2 Interface Connectors

The NV200 Spectral validator has two connectors that are used to allow interfacing and
programming; these connectors are easily accessible at the back of the validator.
Information
Power always required
regardless of connection
type.
The first connector is a 16-pin socket used to interface the NV200 Spectral to the host
machine. The pin numbering of the socket is shown below, as well as an overview of
the socket connections:
When a Payout, Ticket Module or Docking Plate is connected a 16-pin Molex
0039012165 connector will replace the 16-pin Molex 9733272, the Pinout is below:
Copyright © Innovative Technology Ltd 2019
Caution!
The use of an encrypted protocol
(preferable eSSP) is strongly
recommended to achieve the
highest security!
Power is always required on pins 15(+V) and
16(0V) of the 16-way connector.
