User Manual NV200 Spectral Range
<< Back to Contents
To open the second door, press the red latch inside the first door as per the picture
below. The second door will spring open:
Notes can now be removed from both areas where visible. Once the notes are removed
follow the next step to ensure that tapes are properly tensioned.
2) Tension tapes
Using the small hex key that comes with the module, wind the tapes slightly until
the tapes are properly tensioned. If they are already correctly tensioned then
you do not need to wind tapes.
Copyright © Innovative Technology Ltd 2019
Doc: GA02119 User Manual NV200 Spectral Range
Version: 2.2
Page 84 of 113
