Table 3-14 COP Header (P50) (continued)
Pin
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
3.4.2.5

XMC Connector (XJ1)

The MVME2502 supports two XMC sites. The board only support J15 for XMC site 1 and
J25 for XMC site 2.

Table 3-15 XMC Connector (XJ1) Pin out

Pin Row A
1 RX0 +
2 GND
3 NC
4 GND
MVME2502 Installation and Use (6806800R96L)
Signal Description
COP QACK
JTAG TDI
COP TRST
COP RUNSTOP (Pulled UP)
COP VDD SENSE
JTAG TCK
COP CHECK STOP IN
JTAG TMS
NC
P2020 SW RESET
COP PRESENT
COP HARD RESET
KEYING
COP CHECK STOP OUT
GND
Row B Row C
RX0 - +3.3V
GND JTAG TRST
NC +3.3V
GND JTAG TCK
Controls, LEDs, and Connectors
Row D Row E
NC NC
GND GND
NC NC
GND GND
Row F
+3.3V
HRESET
+3.3V
MRSTO
(PULLED UP)
