2.3.1

Environmental Requirements

Operating temperatures refer to the temperature of the air circulating around the
board and not to the component temperature.
Table 2-1
Characteristics
Applicable Variants
Cooling Method
Operating Temperature
Storage
Vibration Sine
(10min/axis)
Vibration Random
(1hr/axis)
Shock
Humidity
1. Flat 15-1000Hz, -6db/octave 1000Hz - 2000Hz [MIL-STD 810F Figure 514.5C-17]
Product Damage
High humidity and condensation on the board surface causes short circuits.
Do not operate the board outside the specified environmental limits.
Make sure that the board is completely dry and there is no moisture on any surface
before applying power.
MVME2502 Installation and Use (6806800R96L)
Environmental Requirements
Commercial Versions
MVME2502-02120201E
MVME2502-02120201S
Forced Air 7CFM
0°C to +55°C
-40°C to +85°C
2G, 5 to 500Hz
2
0.002g /Hz, 15 to 2000Hz
(2GRMS)
20g/11mS
to 95% RH (non-condensing)
Hardware Preparation and Installation
Extended Temperature Versions
MVME2502-02100202E
MVME2502-02100202S
MVME2502-021CCxxxx
Forced Air 7CFM
-40°C to +71°C
-50°C to +100°C
5G, 15 to 2000Hz
0.04g
(8GRMS)
30g/11mS
to 95% RH (non-condensing)
to 100% RH (non-condensing,
CC variants)
NOTICE
2
/Hz, 15 to 2000Hz
1
35
