Controls, LEDs, and Connectors
3.4.1.2

Front Panel Serial Port (COM1)

There is one front access asynchronous serial port interface labeled COM1 that is routed
to the micro mini DB-9 front panel connector. A male-to-male micro-mini DB9 adapter cable
is available under Penguin Edge part number SERIAL-MINI-D (30-W2400E01A). The pin
assignments for these connectors are as follows:
Table 3-4
Pin
1
2
3
4
5
6
7
8
9
3.4.1.3

USB Connector

The MVME2502 uses upright USB receptacle mounted in the front panel.
Table 3-5
Pin Name
1
2
3
4
52
Front Panel Serial Port
Signal Description
NC
RX
TX
NC
GND
NC
RTS
CTS
NC
USB Connector
Signal Description
+5V
Data -
Data +
GND
Controls, LEDs, and Connectors
MVME2502 Installation and Use (6806800R96L)
