9. Connect the cables to the transition module.
Removal Procedure
1. Turn off the power.
2. Disconnect all the cables.
3. Press the red locking tabs (IEEE handles only) to eject the board.
4. Loosen and remove the screws adjacent to the injector/ejector levers that securing the
module to the chassis.
5. Move the injector/ejector levers in outward direction.
6. Slide the module from the chassis and make sure that no damage is caused to the pins.
7. Remove the transition module from the chassis and insert the filler panels.
2.5.2

PMC/XMC Support

Installation Procedure
Read all notices and follow these steps to install a PMC on the baseboard.
Damage of Circuits
Electrostatic discharge and incorrect installation and removal can damage circuits
or shorten its life.
Before touching the board or electronic components, make sure that you are
working in an ESD-safe environment.
Product Damage
Inserting or removing modules with power applied may result in damage to module
components.
Before installing or removing additional devices or modules, read the
documentation that came with the product.
1. Attach an ESD strap to your wrist. Attach the other end of the strap to the chassis as a
ground. Make sure that it is securely fastened throughout the procedure.
2. Remove the PMC/XMC filler plate from the front panel cut-out.
3. Slide the front bezel of the PMC/XMC into the front panel cut-out from backside. The
front bezel of the PMC/XMC module will be placed with the board when the connectors
on the module align with the connectors on the board.
