Hardware Preparation and Installation

2.1

Overview

This chapter provides unpacking instructions, hardware preparation, installation
procedures of the board. Installation instructions for the optional PMC/XMC modules and
transitions modules are also included.
A fully implemented MVME2502 consists of the base board and the following modules:
PCI Mezzanine Card (PMC) or PCI-E Mezzanine Card (XMC) for added versatility

Rear transition module

SATA kit

NOTE: MVME2502-HDMNKIT1/MVME2502-HDMNKIT2 is provided based on purchase
order.
The following are the steps to be performed before using the board. Be sure to read the
entire chapter, including all caution and warning notes, before you begin.
1. Unpack the hardware. Refer to
2. Configure the hardware by setting jumpers on the board and the RTM. Refer to
Configuring the Board on page 37.
3. Install the rear transition module in the chassis. Refer to
page 38.
4. Install PMC module (if required). Refer to
5. Install XMC span module (if required). Refer to
6. If purchased, install MVME2502-HDMNKIT1/MVME2502-HDMNKIT2. Refer to
Installation of MVME2502-HDMNTKIT1/MVME2502-HDMNTKIT2 on page
7. Install the board in the chassis. Refer to
8. Attach cables and apply power. Refer to
MVME2502 Installation and Use (6806800R96L)
Unpacking and Inspecting the Board on page 34.
PMC/XMC Support on page
PMC/XMC Support on page
Installing and Removing the Board on page
Completing the Installation on page
Chapter 2
Rear Transition Module on
39.
39.
40.
44.
43.
33
