Boot System
These serial access parameters are the default values. These values can be changed
within the U-Boot. For details, refer to the U-Boot documentation.
3. Boot the MVME2502.
4. When prompted, press the <h> key.
U-Boot aborts the boot sequence and enters into a command line interface mode.
Enter the command
boot feature and let the U-Boot directly enter the command line interface after the
next reboot/power up.
6.3

Boot Options

6.3.1

Booting from a Network

In this mode, U-Boot downloads and boots the Linux kernel from an external TFTP server
and mounts a root file system located on a network server.
1. Make sure that the kernel, dtb, and ramdisk are accessible to the board from the
TFTP server.
2. Configure U-Boot environment variables:
setenv ipaddr <IP address of MVME2502>
setenv serverip <IP address of TFTP server>
setenv gatewayip <gateway IP>
setenv netmask <netmask>
setenv bootargs 'root=/dev/ram rw console=ttyS0,9600n8
ramdisk_size=700000 cache-sram-size=0x10000'
saveenv
3. Transfer the files through the TFTP from the server to the local memory.
tftp 1000000 <kernel_image>
tftp 2000000 <ramdisk>
tftp C00000 <kernel dtb>
4. Boot the Linux from the memory.
bootm 1000000 2000000 c00000
120
setenv bootdelay -1; saveenv
MVME2502 Installation and Use (6806800R96L)
to disable the U-Boot auto-
Boot System
