7.3

Interrupt Controller

The MVME2502 uses the MPC8548E integrated programmable interrupt controller (PIC)
to manage locally generated interrupts. Currently defined external interrupting devices,
interrupt assignments, along with corresponding edge/levels, and polarities are shown in
the following table.
Table 7-2
Interrupt Line
IRQ0
IRQ1
IRQ2
IRQ3
IRQ4
IRQ5
IRQ6
IRQ7/ GPIO0
MVME2502 Installation and Use (6806800R96L)
POR Configuration Settings (continued)
CONFIG PINS
LA[28]
TSEC2_TXD_5
MVME2502 Interrupt List
Interrupt Usage
(Schematic)
None
QUART_IRQ1
QUART_IRQ2
QUART_IRQ3
Temperature
Interrupt
Ethernet 1
Ethernet 3
Ethernet 2
CONFIG SELECTION
SYSCLOCK is above
1
66 MHz
1 Not Inverted
Default
Interface to CPU Description
Reserved for VME interrupt
LBC RTB Quart Interrupt
LBC RTB Quart Interrupt
LBC RTB Quart Interrupt
Two on-board Thermal Sensors:
I2C one is for CPU temp and the other
is for board temp
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
Ethernet interrupt is handled by
Management I2C
PHY/ Connected for flexibility
Programming Model
REMARKS
RapidIO is not used
