Programming Model

7.7.3

Local Bus Controller Clock Divisor

The local bus controller (LBC) clock output is connected to the CPLD for LBC bus

transaction. It is also the source of 1 MHz (CPU_RTC) and CPLD tick timers.

MVME2502 Installation and Use (6806800R96L)

139
