3.2

Front Panel

The following components are found on the MVME2502 ENP1 and ENP2 front panel.

Figure 3-3 Front Panel LEDs, Connectors and Switches

MVME2502 Installation and Use (6806800R96L)
PMC/XMC 2
PMC/XMC 1
USER 1
RESET
SERIAL
SWITCH
PORT
FAIL
USB
SPEED
eTSEC 1
ACT
SPEED
eTSEC 2
ACT
Controls, LEDs, and Connectors
47
