Controls, LEDs, and Connectors
Table 3-10 PMC J12/J222 Connector (continued)
Pin
24
25
26
27
28
29
30
31
32
Table 3-11
Pin
1
2
3
4
5
6
7
8
9
10
11
12
60
Signal Description
+3.3V
IDSEL
AD 23
+3.3V
AD 28
AD 18
GND
AD 16
CBE2
PMC J13/J333 Connector
Signal Description
NC
GND
GND
CBE7
CBE6
CBE5
CBE4
GND
+3.3V
PAR64
+3.3V
AD 62
Controls, LEDs, and Connectors
Pin
Signal Description
56
GND
57
NC
58
EREADY
59
GND
60
RSTOUT
61
ACK64
62
+3.3V
63
GND
64
NC
Pin
Signal Description
33
GND
34
AD48
35
AD 47
36
AD 52
37
AD 45
38
GND
39
+3.3V
40
AD 40
41
AD 43
42
AD 42
43
AD 41
44
GND
