SMART Embedded Computing Penguin Edge MVME250 Series Installation And User Manual page 55

Table 3-7
Pin
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
MVME2502 Installation and Use (6806800R96L)
VMEbus P2 Connector (continued)
Row A Row B
PMC IO 16 ADDRESS 28
PMC IO 18 ADDRESS 29
PMC IO 20 ADDRESS 30
PMC IO 22 ADDRESS 31
PMC IO 24 GND
PMC IO 26 +5V
PMC IO 28 DATA 16
PMC IO 30 DATA 17
PMC IO 32 DATA 18
PMC IO 34 DATA 19
PMC IO 36 DATA 20
PMC IO 38 DATA 21
PMC IO 40 DATA 22
PMC IO 42 DATA 23
PMC IO 44 GND
PMC IO 46 DATA 24
PMC IO 48 DATA 25
PMC IO 50 DATA 26
PMC IO 52 DATA 27
PMC IO 54 DATA 28
PMC IO 56 DATA 29
PMC IO 58 DATA 30
PMC IO 60 DATA 31
Controls, LEDs, and Connectors
Row C Row D
PMC IO 15 GE3_2 -
PMC IO 17 GND
PMC IO 19 GE3_3 +
PMC IO 21 GE3_3 -
PMC IO 23 GND
PMC IO 25 I2C DATA
PMC IO 27 I2C CLK
GE3_LINK_
PMC IO 29
LED
PMC IO 31 GE3_ACT_LED GND
PMC IO 33 GE4_LINK_LED Serial 3 RX
PMC IO 35 GE4_A_LED
PMC IO 37 GND
PMC IO 39 GE4_3 -
PMC IO 41 GE4_3 +
PMC IO 43 GND
PMC IO 45 GE4_2 -
PMC IO 47 GE4_2+
PMC IO 49 GND
PMC IO 51 GE4_1 -
PMC IO 53 GE4_1 +
PMC IO 55 GND
PMC IO 57 GE4_0 -
PMC IO 59 GE4_0 +
Row Z
GND
Serial 2 RX
GND
Serial 2 TX
GND
Serial 2 CTS
GND
Serial 2 RTS
GND
Serial 3 TX
GND
Serial 3 CTS
GND
Serial 3 RTS
GND
Serial 4 RX
GND
Serial 4 TX
GND
Serial 4 CTS
GND
55
