Chapter 3

Controls, LEDs, and Connectors

3.1

Board Layout

The following figure shows the components and connectors on the MVME2502 board.

Figure 3-1 Board Layout ENP1 Variant

MVME2502 Installation and Use (6806800R96L)
45
