5.6.4

Counter High and Low Word Registers

When enabled, the tick timer counter register increments every microsecond. Software
may read or write the counter at any time.

Table 5-29 Counter High Word Registers

Tick Timer 0 Counter Value High Word - 0xFFC80208
REG Tick Timer 1 Counter Value High Word - 0xFFC80308
Tick Timer 2 Counter Value High Word - 0xFFC80408
Bit 15
Field TickTimer Counter Value High Word (16-bits)
OPER R/W
RESET 0x0000

Table 5-30 Counter Low Word Registers

Tick Timer 0 Counter Value Low Word - 0xFFC8020A
REG Tick Timer 1 Counter Value Low Word - 0xFFC8030A
Tick Timer 2 Counter Value Low Word - 0xFFC8040A
Bit 15
Field TickTimer Counter Value Low Word (16-bits)
OPER R/W
RESET 0x0000
MVME2502 Installation and Use (6806800R96L)
14 13 12 11 10
14 13 12 11 10
Memory Maps and Registers
9 8 7 6 5
9 8 7 6 5
4 3 2 1 0
4 3 2 1 0
117
