3.4.2.2

PMC Connectors

The MVME2502 supports two PMC sites. It utilizes J14 to support PMC I/O that goes to the
RTM PMC. The tables below show the pin out detail of J11/J111, J12/J222, J13/J333 and
J14. See
Table 3-9
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
MVME2502 Installation and Use (6806800R96L)
Custom SATA Connector (J3) (continued)
Signal Description
GND
NC
GND
NC
GND
Figure 3-1 for the location of the PMC connectors.
PMC J11/J111 Connector
Signal Description
JTAG TCK
-12V
GND
INT A
INT B
INT C
PRESENT SIGNAL
+5V
INT D
NC
GND
NC
PCI CLK
Controls, LEDs, and Connectors
Pin Signal Description
36 +5V
37 +3.3V
38 +5V
39 +3.3V
40 +5V
Pin Signal Description
33 FRAME
34 GND
35 GND
36 IRDY
37 DEVSEL
38 +5V
39 PCIXCAP
40 LOCK
41 NC
42 NC
43 PAR
44 GND
45 +3.3V
