3.4

Connectors

This section describes the pin assignments and signals for the connectors on the
MVME2502 board.
3.4.1

Front Panel Connectors

The following connectors are found on the outside of the MVME2502 board. These
connectors are divided between the front panel connectors and the backplane connectors.
The front panel connectors include the J1 and the J5 connectors. The backplane
connectors include the P1 and the P2 connectors.
3.4.1.1

RJ-45 with Integrated Magnetics

The MVME2502 uses an X2 RJ-45.
Table 3-3
Pin Name
1
2
3
4
5
6
7
8
9
10
MVME2502 Installation and Use (6806800R96L)
Ethernet Tri-Speed RJ-45 Connectors (GENET1 and GENET2)
Signal Description
GND
NC
TRD3 -
TRD3 +
TRD2 -
TRD2 +
TRD1 -
TRD1 +
TRD0 -
TRD0 +
Controls, LEDs, and Connectors
51
