1.2

Standard Compliances

The product is designed to meet the following standards:
Table 1-1
Standard
EN 60950-1/A11:2009
IEC 60950-1:2005 2nd Edition
CAN/CSA C22.2 No 60950-1
FCC Part 15, Subpart B, Class A (non-
residential)
ICES-003, Class A (non-residential)
EMC Directive 89/336/EEC
EN55022 Class B
EN55024
AS/NZS CISPR 22, Class A
EN300386
ETSI EN 300 019 series
Directive (EU) 2015/863 (amending
Annex II to Directive 2011/65/EU)
1.3

Mechanical Data

The following table provides the dimensions and the weight of the board.
Table 1-2
Feature
Height
Depth
Front Panel Height
Width
Max. Component Height
Weight
MVME2502 Installation and Use (6806800R96L)
Board Standard Compliances
Mechanical Data
Description
Safety Requirements (legal)
EMC requirements (legal) on system level (predefined
Penguin Solutions system)
Environmental Requirements
Directive on the restriction of the use of certain hazardous
substances in electrical and electronic equipment
(RoHS).
Value
233.44mm (9.2 inches)
160.0mm (6.3 inches)
261.8mm (10.3 inches)
19.8mm (0.8 inches)
14.8mm (0.58 inches)
400 grams (ENP1), 700 grams (ENP2)
