7.7.1

System Clock

The system and DDR clock is driven by ICS840S07I device. The following table defines the
clock frequency.
Table 7-7
SYSCLK
100MHz
7.7.2

Real Time Clock Input

The RTC clock input is driven by 1 MHz clock generated by the CPLD. This provides a fixed
clock reference for the QorIQ P2020 PIC timers which the software can use as a known
time reference.
138
Clock Distribution (continued)
Clock Signal
CLK_PCIEC3
CLK_88SE9125_PCIE_100
MHZ
CLK_CPLD
CLK_USB_1_24MHZ
CPU_RTC
CLK_PMC1
CLK_PCI_BR3
CLK_32K
CPU_LCK0
CLK_QUART
CLK_25MHZ_ICS9FG108
System Clock
CORE
800/1200MHz
Frequency
100MHz
100MHz
1.8432MHz
24MHz
1MHz
33/66/100/133
MHz
133MHz
32.768KHz
25MHz
1.8432MHz
25MHz
CCB Clock (Platform)
400MHz
MVME2502 Installation and Use (6806800R96L)
Programming Model
Clock Tree
VIO
Source
ICS9FG111 DIFF
ICS9FG112 DIFF
Oscillator +3.3V
Oscillator +3.3V
CPLD +3.3V
TSI384 +3.3V
ICS840S07I +3.3V
DS32KHz +3.3V
QorIQ P2020 +3.3V
CPLD +3.3V
ICS83905AGILF +3.3V
DDR3 LBC
400MHz 25MHz
