INVT Goodrive 200L Operation Manual page 153

inverters
Goodrive200L
ADDR
CMD
Byte number
Data high bit of address 0004H
Data low bit of address 0004H
Data high bit of address 0005H
Data low bit of address 0005H
CRC CHK low bit
CRC CHK high bit
END
The meaning of the response is that:
ADDR = 01H means the command message is sent to the inverter with the address of 01H
and ADDR occupies one byte
CMD=03H means the message is received from the inverter to the master for the response
of reading command and CMD occupies one byte
"Byte number" means all byte number from the byte(excluding the byte) to CRC
byte(excluding the byte). 04 means there are 4 byte of data from the "byte number" to "CRC
CHK low bit", which are "digital address 0004H high bit", "digital address 0004H low bit",
"digital address 0005H high bit" and "digital address 0005H low bit".
There are 2 bytes stored in one data with the fact that the high bit is in the front and the low
bit is in the behind of the message, the data of data address 0004H is 1388H, and the data
of data address 0005H is 0000H.
CRC occupies 2 bytes with the fact that the high bit is in the front and the low bit is in the
behind.
9.4.2 Command code: 06H
06H (correspond to binary 0000 0110), write one word(Word)
The command means that the master write data to the inverter and one command can write
one data other than multiple dates. The effect is to change the working mode of the inverter.
For example, write 5000 (1388H) to 0004H from the inverter with the address of 02H, the
frame structure is as below:
RTU master command message (from the master to the inverter)
START
ADDR
CMD
High bit of write data address
Low bit of write data address
High bit of data content
Low bit of data content
CRC CHK low bit
CRC CHK high bit
END
RTU slave response message (from the inverter to the master)
T1-T2-T3-T4 (transmission time of 3.5 bytes)
T1-T2-T3-T4(transmission time of 3.5 bytes)
T1-T2-T3-T4 (transmission time of 3.5 bytes)
148
Communication protocol
01H
03H
04H
13H
88H
00H
00H
7EH
9DH
02H
06H
00H
04H
13H
88H
C5H
6EH
