Goodrive200L
The function code which can improve the elevator comfort of stopping is showed as follow:
P08.02: The start time of S-curve stopping setting
P08.03: The arrival time of S-curve stopping setting
P00.12: Deceleration time;
P03.00: ASR speed proportion gain 1
P03.01: ASR speed integral time 1
11. Emergency running function
Function
Name
Code
The control
selection of
P01.30 emergency
running
direction
Emergency
P01.31 running
frequency
Y output
P06.01
selection
HDO output
P06.02
selection
RO1relay
P06.03 output
selection
RO2 relay
output
P06.04
selection
It can support single phase UPS or ARD for emergency running. The configuration of the
UPS or ARD is 1PH 220VAC or 3PH 380VAC. The detection of the losing phase and under
voltage parameters are no need to be changed.
In emergency running mode, there are two way for changing the running direction of elevator
by setting the parameter of P01.30.
a. When the inverter can't actuate the motor, inverter will output the signal to the
Description
0:External controller
1:Inverter
0.00Hz~P00.03(max
frequency)
0:Without output
1:Running
2: Forward rotation
3: Reversal rotation
5:Inverter fault
6:The detection of
frequency level FDT1
7:The detection of
frequency level FDT2
14:Overload
forewarning
27: Under the
emergency running
state, require to
change the direction
of motor. (P01.30 is
valid)
29: SPI fault detection
output
122
Basic operation instruction
Range Modify
○
0~1
○
0.00~P00.03
○
0~30
○
0~30
○
0~30
○
0~30
Factory
setting
0
5.00Hz
27
0
1(Output
connects
to the
running
contactor.)
6(Output
connects
to the
braking
contactor.)
