INVT Goodrive 200L Operation Manual page 31

inverters
Goodrive200L
No. Name
Mean the unit displayed currently
Unit
2
LED
Code
5-figure LED display displays various monitoring data and alarm code such
displayi
3
as set frequency and output frequency.
ng zone
Digital
potentio Tuning frequency. Please refer to P08.42.
4
meter
5 Buttons
LOCAL/REMOT
TRIP
Programming key
Entry key
UP key
DOWN key
Right-shift key
26
Keypad operation procedure
Description
state
LED for keypad operation, terminals
operation and remote communication
control
LED off means that the inverter is in the
keypad operation state; LED blinking
means the inverter is in the terminals
operation state; LED on means the
inverter is in the remote communication
control state.
LED for faults
LED on when the inverter is in the fault
state; LED off in normal state; LED
blinking means the inverter is in the
pre-alarm state.
Hz
RPM
A
%
V
Enter or escape from the first level
menu and remove the parameter
quickly
Enter the menu step-by-step
Confirm parameters
Increase data or function code
progressively
Decrease data or function code
progressively
Move right to select the displaying
parameter circularly in stopping and
running mode.
Select the parameter modifying digit
Frequency unit
Rotating speed unit
Current unit
Percentage
Voltage unit
