INVT Goodrive 200L Operation Manual page 120

inverters
Goodrive200L
Function
Name
code
S2 terminal
P05.02 function
selection
S3 terminal
P05.03 function
selection
S4 terminal
P05.04 function
selection
S5 terminal
P05.05 function
selection
S6 terminal
P05.06 function
selection
S7 terminal
P05.07 function
selection
S8 terminal
P05.08 function
selection
HDI terminal
P05.09 function
selection
6. Multi-step speed
Function
Name
code
Multi-step
P10.02
speed0
Multi-step
P10.04
speed1
Multi-step
P10.06
speed2
Multi-step
P10.08
speed3
Multi-step
P10.10
speed4
Multi-step
P10.12
speed5
Description
2: Reverse direction
running
16:Multi-step speed
terminal 1
17:Multi-step speed
terminal 2
18:Multi-step speed
terminal 3
19:Multi-step speed
terminal 4
42: Contactor
feedback signal
43: Braker feedback
signal
44: Emergency
running enable
Description
Multi-step speed0
Multi-step speed1
Multi-step speed2
Multi-step speed3
Multi-step speed4
Multi-step speed5
115
Basic operation instruction
Setting
Modify
Range
◎
0~63
◎
0~63
◎
0~63
◎
0~63
◎
0~63
◎
0~63
◎
0~63
◎
0~63
Setting
Modify
Range
0~Max
○
frequency
0~Max
○
frequency
0~Max
○
frequency
0~Max
○
frequency
0~Max
○
frequency
0~Max
○
frequency
Factory
setting
2
16
17
18
19
42
43
44
Factory
setting
0.0 HZ
5.0 HZ
15.0 HZ
50.0 HZ
0.0 HZ
0.0 HZ
