Current running
command
channel
P00.01
Keypad running
command channel
Terminal running
command channel
Communication
running command
channel
Note: "/" means the multi-function terminal is invalid on the current reference channel.
Relative parameters table:
7.3 Vector control
Because asynchronous motors have the characteristics of high stage, nonlinear, strong
coupling and various variables, the actual control of the asynchronous motor is very difficult.
Vector control is mainly used to settle this problem with the theme of that divide the stator
current vector into exciting current (the current heft generating internal magnetic field of the
motor) and torque current (the current heft generating torque) by controlling and measuring
the stator current vector according to the principles of beamed magnetic field to control the
range and phase of these two hefts. This method can realize the decoupling of exciting
current and torque current to adjust the high performance of asynchronous motors.
Goodrive200L series inverters are embedded speedless sensor vector control calculation for
driving both asynchronous motors and synchronous motors. Because the core calculation of
vector control is based on exact motor parameter models, the accuracy of motor parameter
will impact on the performance of vector control. It is recommended to input the motor
parameters and carry out autotune before vector running.
Because the vector control calculation is vary complicated, high technical theory is needed
for the user during internal autotune. It is recommended to use the specific function
parameters in vector control with cautions.
Multi-function
terminal 36
Shifting the
command to keypad
/
Keypad running
command channel
Keypad running
command channel
Basic operation instruction
Multi-function
terminal 37
Shifting the
command to
communication
Terminal running
command channel
/
Terminal running
command channel
100
Multi-function
terminal 38
Shifting the
command to
communication
Communication
running command
channel
Communication
running command
channel
/
