INVT Goodrive 200L Operation Manual page 23

inverters
Goodrive200L
Terminal
≤30kW
R, S, T Power input of the main circuit
U, V, W
This terminal is
P1
inexistent
Braking resistor
(+)
1
(-) /
Braking resistor
PB
terminal 2
380V:the grounding resistor is less
PE
Fig 4-14 220~315kW terminals of main circuit
Fig 4-15 350~500kW terminals of main circuit
Terminal name
≥37kW
The inverter output
DC reactor terminal 1 P1 and (+) are connected with the
DC reactor terminal 2,
braking unit terminal 1
Braking unit terminal 2
This terminal is
inexistent.
than 10Ohm
3-phase AC input terminals which are
generally connected with the power
supply.
3-phase AC output terminals which are
generally connected with the motor.
terminals of DC reactor.
(+) and (-) are connected with the
terminals of braking unit.
PB and (+) are connected with the
terminals of braking resistor.
Protective grounding terminals, every
machine is provided 2 PE terminals as
the standard configuration. These
terminals should be grounded with
proper techniques.
18
Installation guidelines
Function
