INVT Goodrive 200L Operation Manual page 69

inverters
Goodrive200L
Function
Name
code
QUICK/JOG
P07.02 function
selection
Shifting
sequence
P07.03 selection of
QUICK/JOG
commands
STOP/RST
P07.04
stop function
Parameters
P07.05
state 1
Detailed instruction of parameters
0:No function
1: Jogging. Press QUICK/JOG to begin the
jogging running.
2: Shift the display state by the shifting key.
Press QUICK/JOGto shift the displayed function
code from right to left.
3: Shift between forward rotations and reverse
rotations. Press QUICK/JOG to shift the direction
of the frequency commands. This function is only
valid in the keypad commands channels.
4: Clear UP/DOWN settings. Press QUICK/JOG
to clear the set value of UP/DOWN.
5: Coast to stop. Press QUICK/JOG to coast to
stop.
6: Shift the running commands source. Press
QUICK/JOG to shift the running commands
source.
7:Quick commission mode(committee according
to the non-factory parameter)
Note: Press QUICK/JOGto shift between
forward rotation and reverse rotation, the inverter
does not record the state after shifting during
powering off. The inverter will run according to
parameter P00.13 during next powering on.
When P07.02=6, set the shifting sequence of
running command channels.
0:Keypad control→terminals control
→communication control
1:Keypad control←→terminals control
2:Keypad control←→communication control
3:Terminals control←→communication control
STOP/RST is valid for stop function. STOP/RST
is valid in any state for the fault reset.
0:Only valid for the keypad control
1:Both valid for keypad and terminals control
2:Both valid for keypad and communication
control
3:Valid for all control modes
0x0000~0xFFFF
BIT0:running frequency (Hz on)
BIT1:set frequency(Hz flickering)
64
Function parameters
Default
Modify
value
◎
1
○
0
○
0
○
0x03FF
