INVT Goodrive 200L Operation Manual page 62

inverters
Goodrive200L
Function
Name
code
S6
terminal
P05.25
switching-off
delay time
S7
terminal
P05.26
switching-on
delay time
S7
terminal
P05.27
switching-off
delay time
S8
terminal
P05.28
switching-on
delay time
S8
terminal
P05.29
switching-off
delay time
HDI
terminal
P05.30
switching-on
delay time
HDI
terminal
P05.31
switching-off
delay time
Lower limit of
P05.32
AI1
Correspondin
g setting of
P05.33
the lower
limit of AI1
Upper limit of
P05.34
AI1
Correspondin
g setting of
P05.35
the upper
limit of AI1
Detailed instruction of parameters
The inverter(≤15kW) can be set by the analog
potentiometer on the keypad and AI1 setting is
not available for the device which is 18.5kW or
higer than 18.5 kW.
The function code defines the relationship
between the analog input voltage and its
corresponding set value. If the analog input
voltage beyond the set minimum or maximum
input value, the inverter will count at the minimum
or maximum one.
When the analog input is the current input, the
corresponding voltage of 0~20mA is 0~10V.
57
Function parameters
Default
Modify
value
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.00V
○
0.0%
○
10.00V
○
100.0%
