INVT Goodrive 200L Operation Manual page 97

inverters
Goodrive200L
Function
Name
code
fault
processing
Communicati
P14.06 on
processing
P16 Group Ethernet function
P17 Group Monitoring function
Setting
P17.00
frequency
Output
P17.01
frequency
Ramp
P17.02 reference
frequency
Output
P17.03
voltage
Output
P17.04
current
P17.05 Motor speed
P17.08 Motor power
Output
P17.09
torque
Evaluated
P17.10 motor
frequency
P17.11 DC bus
Detailed instruction of parameters
1:No alarm and continue to run
2:No alarm and stop according to the stop means
(only under the communication control)
3:No alarm and stop according to the stop means
(under all control modes)
LED ones:
0: Operation with response: the drive will respond
to all reading and writing commands of the upper
monitor.
1:Operation without response；The drive only
responds to the reading command other than the
writing command of the drive. The
communication efficiency can be increased by
this method.
LED tens:
0: Communication encrypting valid
1: Communication encrypting invalid
Display current set frequency of the inverter
Range: 0.00Hz~P00.03
Display current output frequency of the inverter
Range: 0.00Hz~P00.03
Display current ramp reference frequency of the
inverter
Range: 0.00Hz~P00.03
Display current output voltage of the inverter
Range: 0~1200V
Display current output current of the inverter
Range: 0.0~3000.0A
Display the rotation speed of the motor.
Range: 0~65535RPM
Display current motor power
Range:-300~300%
Display the current output torque of the inverter.
Range: -250.0~250.0%
Evaluated frequency of motor rotor
Range: 0.00Hz~ P00.03
Display current DC bus voltage of the inverter
92
Function parameters
Default
Modify
value
○
0x00
●
●
●
●
●
●
●
●
●
●
