INVT Goodrive 200L Operation Manual page 58

inverters
Goodrive200L
Function
Name
code
HDI terminal
P05.09 function
selection
Polarity
selection of
P05.10
the input
terminals
ON-OFF filter
P05.11
time
Virtual
P05.12 terminals
setting
Detailed instruction of parameters
22:ACC/DEC time option 2
23:Simple PLC stop reset
24:Simple PLC pause
25:PID control pause
26:Traverse Pause(stop at the current frequency)
27:Traverse reset(return to the center frequency)
28:Counter reset
29:Torque control prohibition
30:ACC/DEC prohibition
31:Counter trigger
32:Length reset
33:Cancel the frequency change setting
temporarily
34:DC brake
36:Shift the command to the keypad
37:Shift the command to the terminals
38:Shift the command to the communication
39: Pre-exciting command
40:Clear the power
41:Keep the power
42: Contactor feedback signal
43: Braker feedback signal
44: Emergency running enable
61: PID pole switching
The function code is used to set the polarity of
the input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT0 BIT1
S1 S2
BIT5 BIT6
S6 S7
The setting range:0x000~0x1FF
Set the sample filter time of S1~S8 and HDI
terminals. If the interference is strong, increase
the parameter to avoid the disoperation.
0.000~1.000s
0x000~0x1FF(0: Disabled, 1:Enabled )
BIT0:S1 virtual terminal
BIT1:S2 virtual terminal
BIT2:S3 virtual terminal
BIT2 BIT3 BIT4
S3 S4 S5
BIT7 BIT8
S8 HDI
53
Function parameters
Default
Modify
value
◎
0
○
0x000
○
0.010s
◎
0x000
