INVT Goodrive 200L Operation Manual page 84

inverters
Goodrive200L
Function
Name
code
Input power
P08.51 factor of the
inverter
P09 Group PID control
PID
P09.00 reference
source
Keypad PID
P09.01
preset
PID feedback
P09.02
source
Detailed instruction of parameters
This function code is used to adjust the displayed
current of the AC input side.
Setting range:0.00~1.00
When the frequency command selection
(P00.06, P00. 07) is 7 or the voltage setting
channel selection (P04.27) is 6, the running
mode of the inverter is procedure PID controlled.
The parameter determines the target reference
channel during the PID procures.
0:Keypad digital reference(P09.01)
1:Analog channel AI1 reference (The inverter
(≤15kW) can be set by the analog potentiometer
on the keypad and AI1 setting is not available for
the device which is 18.5kW or higer than 18.5kW)
2:Analog channel AI2 reference
3:Analog channel AI3 set
4:High speed pulse HDI set
5:Multi-step speed set
6:MODBUS communication set
The setting target of procedure PID is a relative
one, 100% of the setting equals to 100% of the
response of the controlled system.
The system is calculated according to the relative
value (0~100.0%).
Note:
Multi-step speed reference, it is realized by
setting P10 group parameters.
When P09.00=0, set the parameter whose basic
value is the feedback value of the system.
The setting range:-100.0%~100.0%
Select the PID channel by the parameter.
0:Analog channel AI1 feedback (The inverter(≤
15kW) can be set by the analog potentiometer on
the keypad and AI1 setting is not available for the
device which is 18.5kW or higer than 18.5 kW)
1:Analog channel AI2 feedback
2:Analog channel AI3 feedback
3:High speed HDI feedback
4:MODBUS communication feedback
Note: The reference channel and the feedback
79
Function parameters
Default
Modify
value
○
0.56
○
0
○
0.0%
○
0
