INVT Goodrive 200L Operation Manual page 63

inverters
Goodrive200L
Function
Name
code
AI1 input
P05.36
filter time
Lower limit of
P05.37
AI2
Correspondin
g setting of
P05.38
the lower
limit of AI2
Upper limit of
P05.39
AI2
Correspondin
g setting of
P05.40
the upper
limit of AI2
AI2 input
P05.41
filter time
Lower limit of
P05.42
AI3
Correspondin
g setting of
P05.43
the lower
limit of AI3
Middle value
P05.44
of AI3
Correspondin
g middle
P05.45
setting of
AI3
Upper limit of
P05.46
AI3
Correspondin
g setting of
P05.47
the upper
limit of AI3
AI3 input
P05.48
filter time
HDI
P05.49 high-speed
pulse input
Detailed instruction of parameters
In different cases, the corresponding rated value
of 100.0% is different. See the application for
detailed information.
The figure below illustrates different applications:
100%
-10V
Al3
Input filter time: this parameter is used to adjust
the sensitivity of the analog input. Increasing the
value properly can enhance the anti-interference
of the analog, but weaken the sensitivity of the
analog input
Note: Analog AI1 and AI2 can support 0~10V or
0~20mA input, when AI1 and AI2 selects 0~20mA
input, the corresponding voltage of 20mA is 5V.
AI3 can support the output of -10V~+10V.
The setting range of P05.32:0.00V~P05.34
The setting range of P05.33:-100.0%~100.0%
The setting range of P05.34:P05.32~10.00V
The setting range of P05.35:-100.0%~100.0%
The setting range of P05.36:0.000s~10.000s
The setting range of P05.37:0.00V~P05.39
The setting range of P05.38:-100.0%~100.0%
The setting range of P05.39:P05.37~10.00V
The setting range of P05.40:-100.0%~100.0%
The setting range of P05.41:0.000s~10.000s
The setting range of P05.42:-10.00V~P05.44
The setting range of P05.43:-100.0%~100.0%
The setting range of P05.44: P05.42~P05.46
The setting range of P05.45:-100.0%~100.0%
The setting range of P05.46:P05.44~10.00V
The setting range of P05.47:-100.0%~100.0%
The setting range of P05.48:0.000s~10.000s
The function selection when HDI terminals is
high-speed pulse input
0:Frequency setting input, frequency setting
source
Corresponding
setting
AI
10V
20mA
AI1/AI2
-100%
58
Function parameters
Default
Modify
value
○
0.100s
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.100s
○
-10.00V
○
-100.0%
○
0.00V
○
0.0%
○
10.00V
○
100.0%
○
0.100s
◎
0
