1.2 Front-Panel Overview

For the IT6000C series Bi-directional Programmable DC Power Supply, all front
panels of the 3U model are the same, and the operation panels of other models
are the same as those of the 3U model. The following is the front panel sche-
matic of the 3U model.
Model
IT6006C-300-75
300V IT6012C-300-150
IT6018C-300-225
IT6006C-500-40
IT6012C-500-80
500V
IT6018C-500-120
IT6018C-500-120S
IT6006C-800-25
IT6012C-800-50
800V
IT6018C-800-75
IT6018C-800-75S
IT6018C-1500-40
1500V
IT6018C-1500-40S
IT6018C-2250-25
2250V
IT6018C-2250-25S
Naming rules for each series of model are as follows: IT 6XXXC-YYY-ZZZ,
wherein, XXX means rated power; YYY means rated voltage; and ZZZ
means rated current. The IT6018C-500-90S, IT6018C-800-60S, IT6018C-
1500-30S, and IT6018C-2250-20S are slave models, and the specifications
are the same as the corresponding master models.
As a bipolar power supply, this series can output and absorb electric energy.
The current and power input capacity is same as the output capacity. For ex-
ample, the maximum rated value of the output power of the IT6018C-500-90
model is 18,000W, and the maximum rated value of input power is also
18,000W.
