5.11.2 IO–2. Ps, Not-Invert
Parameter Description
IO–2. Ps, Not-
Invert
How to Use
When pin 2 is set to default Ps function, pin 2 will output high or low level based
on whether the instrument is under protection or not. Under normal conditions
(Not under protection), and when pin 2 is under default setting (Not-Invert), pin
Parameter setting for pin 2.
Not- Indicates whether to invert the input/output
Invert pulse or level signal.
•
Invert
•
Ps
Input
Output
Copyright © Itech Electronic Co., Ltd.
Invert: Yes
Not-Invert: No
This default function means the output
level from pin 2, which displays that
whether the instrument is under pro-
tection or not.
Pin 2 receives the level signal from
the outside.
Pin 2 sends the digital signal (1, 0,
PWM) to the outside.
True By default (Not-Invert), the
output digital signal is 1 (i.e.
low level), and in the case of
Invert, the output is high
level.
False By default (Not-Invert), the
output digital signal is 0 (i.e.
high level), and in the case of
Invert, the output is low level.
PWM Digital signal of PWM.
PWM Freq
PWM Duty
Basic Operation
Frequency
Duty cycle
