LV123 LV123 waveform protocol
Curv- Choose to recall the standard LV123 waveform.
e
Run
Open
Edit
Copyright © Itech Electronic Co., Ltd.
Run the presently recalled waveform.
Recall the waveform saved inside the
instrument.
Recall The address of the waveform file,
File ranging from 1 to 10.
Edit the waveform curve.
unlimit- Range of unlimited operating capabil-
ed ity, includes the following options:
•
HV_1
•
HV_2a
•
HV_2b
•
HV_3
upper- Range of upper limited operating ca-
limited pability, includes the following
options:
•
HV_1
•
HV_2a
•
HV_2b
•
HV_3
lower- Range of lower limited operating ca-
limited pability, includes the following
options:
•
HV_1
•
HV_2a
•
HV_2b
•
HV_3
highly- Range of highly limited operating ca-
limited pability, includes the following
options:
•
HV_1
•
HV_2a
•
HV_2b
