4. Set the value of Source and press [Enter].
5. Set the value of Data Type and press [Enter].
Select the Trigger Method
See the steps in the
the data logging is triggered.
Start Data Logging
At this point, the VFD screen returns to the main interface of the system.
5.8 Select Trigger Source (Trig Source)
This setting result is only valid for data recording function. When List function
is used, the method for triggering the running of List files needs to be addi-
tionally set (by default, triggered by the panel).
Before this operation, make sure to connect the USB memory de-
vice to the memory port on the front panel (The USB interface on
the rear panel can only be used for connecting the PC) so that the
recorded data can be stored in the external storage device. Other-
wise, the Data Recording function is not available for usage.
Do not connect the USB communication interface on the rear panel
to the PC, otherwise the Data Recording function will be unavail-
able. If you need a communication connection with a PC, use a
communication interface other than USB, such as LAN.
Manual
Press the composite button [Shift] + [On/Off] (Trigger) on the front panel to
trigger.
Bus
Triggered by the SCPI instruction, for example, when the instrument re-
ceives the trigger command *TRG, a trigger operation is performed.
External
Connect to pin 4 of the digital I/O interface (P-IO) and set pin 4 to Ext-Trig→-
Trig-In→Dlog to trigger.
For details, see
5.11.4 IO–4. Ext-Trig,
Copyright © Itech Electronic Co., Ltd.
section to set how
Not-Invert.
Basic Operation
117
