1.2 Front-Panel Overview

For the IT6000D series High power Programmable DC Power Supply, all front
panels of the 3U model are the same, and the operation panels of other models
are the same as those of the 3U model. The following is the front panel sche-
matic of the 3U model.
Model
IT6018D-500-120
IT6018D-500-120S
IT6006D-800-25
IT6012D-800-50
800V
IT6018D-800-75
IT6018D-800-75S
IT6018D-1500-40
1500V
IT6018D-1500-40S
IT6018D-2250-25
2250V
IT6018D-2250-25S
Naming rules for each series of model are as follows: IT 6XXXD-YYY-ZZZ,
wherein, XXX means rated power; YYY means rated voltage; and ZZZ
means rated current. The IT6018D-500-90S, IT6018D-800-60S, IT6018D-
1500-30S, and IT6018D-2250-20S are slave models, and the specifications
are the same as the corresponding master models.
